• Broadband 9 GHz to 15 GHz
• Linearly Polarized
• 10 dBi Nominal Gain
• Impedance: 50 Ohm
• Connector: SMA Female
• Material: Aluminum Alloy/Titanium
• Temperature: -10÷85 𝐶
| Parameters | Value |
|---|---|
| VSWR | 2 |
| Gain, dB | 10 |
| Impendance, Ohm | 50 |
| Lower Frequency, GHz | 9 |
| Upper Frequency, GHz | 15 |
You can request a quote for this product by filling out this form.
Please contact us for all available specifications and configurations.
